What is the working principle of the double shaft shredder?

Time：2022-11-24 15:11:09

The crushing principle of the double-shaft shredder is that the two cutter shafts are equipped with staggered blades, and the two cutter shafts are shredded by the shearing of the blades and the tearing of the teeth during the rotation of the two shafts. The main shearing mode is the shearing action of the adjacent moving knife edge, and the secondary shearing mode is the tearing action of the moving knife teeth. In terms of equipment structure, the double-shaft shredder is mainly composed of the following parts: the structure of the shredder consists of a lower box, an upper box, an inner partition, a knife shaft, a moving knife, a moving knife spacer, a roller bearing, It is composed of fixed knife, fixed knife fixed plate and corresponding sealing structure.

Working principle of double shaft shredder:

The crushing principle of the double-shaft shredder is that the two cutter shafts are equipped with staggered blades, and the two cutter shafts are shredded by the shearing of the blades and the tearing of the teeth during the rotation of the two shafts. The main shearing mode is the shearing action of the adjacent moving knife edge, and the secondary shearing mode is the tearing action of the moving knife teeth.

The blade of the moving knife will be worn during normal use. After the wear reaches a certain level, it needs to be repaired or replaced in time, otherwise it will not only affect the output and crushing effect, but also affect the normal operation of the equipment. The size of the gap between the two moving knives has an important impact on the output of the equipment. The size range of tool gap is 0.1~0.2mm.

<strongAdditional functions of SUNY GROUP double shaft shredder:

①: Bearing automatic oil lubrication and no oil alarm function

②: Bearing temperature monitoring, high temperature alarm, ultra-high temperature automatic shutdown protection function

③: The motor has overheating and overload protection functions

④: Unbreakable object alarm reminder function

⑤: Reducer lubricating oil replacement alarm reminder function

Double-shaft shredders are widely used in industrial waste, domestic waste, municipal waste, garden waste, medical waste, kitchen waste, biomass shredding and other fields to achieve waste volume reduction and recycling, thereby beautifying the urban environment and improving people's lives. purpose of environmental quality. If you have more questions about the double shaft shredder, please feel free to contact us for consultation.
